Drop Arm Barrier
Model: LK-DAB-SS
Key Features
- Vertical drop arm mechanism
- SUS304 stainless steel construction
- Emergency auto-retract on power failure
- Wiegand 26/34 and RS485 reader interface
- LED traffic indicator lights
- Bi-directional entry and exit control
- Compatible with RFID, biometric, QR, and ticket scanners
- Low power consumption
📍 Supplied from Dubai, UAE · Technical support available
Technical Specifications
| Cabinet Material | SUS304 Stainless Steel |
| Mechanism | Vertical drop arm |
| Lane Width | 550–700 mm |
| Power Supply | DC 12V / 24V |
| Interface | Wiegand 26/34, RS485 |
| Operating Temperature | -20°C to +60°C |
| Emergency Mode | Auto-retract on power failure |
| Direction | Bi-directional |
| LED Indicators | Green / Red |
| Protection Rating | IP42 |
Product Description
Drop Arm Barrier Dubai UAE — Pedestrian Access Control
The LOKIZ Drop Arm Barrier is a compact pedestrian access control barrier using a vertical drop arm mechanism to allow or deny entry. Ideal for car parks, gyms, leisure centres, swimming pools, theme parks, and ticket-based entry points across Dubai and the UAE, drop arm barriers provide a cost-effective and space-efficient alternative to traditional tripod turnstiles.
LOKIZ drop arm barriers feature SUS304 stainless steel construction, Wiegand 26/34 and RS485 interfaces compatible with RFID card readers, biometric terminals, QR code scanners, and access control systems. Emergency mode automatically retracts the arm on power failure for safe evacuation — compliant with UAE Civil Defence requirements.
Drop Arm Barrier Features
✔ Vertical drop arm mechanism — clean and compact design
✔ SUS304 stainless steel construction
✔ Wiegand 26/34 and RS485 reader interface
✔ RFID, biometric, QR, and ticket scanner compatible
✔ Emergency auto-retract on power failure
✔ Bi-directional entry and exit control
✔ LED traffic indicator lights
✔ Low power consumption
✔ Dubai warehouse stock — fast UAE delivery
✔ 12+ years supplying access control and entrance control hardware in UAE
